Time to put one of my spare Raspberry Pis to work #

I woke up this morning and thought, ‘Hey why not get a full BTC node running on one of those Pis you got laying around?’ So that’s what I’m doing today.

Basics #

This assumes something like Raspbian Lite is already installed and SSH access configured. For Wifi, I use these Edimax USB chips. Configuring them is not too difficult. It boils down a simple config in /etc/network/interfaces/

auto lo

iface lo inet loopback
iface eth0 inet dhcp

auto wlan0
allow-hotplug wlan0
iface wlan0 inet dhcp
wpa-ssid "**YOUR_WIFI**"
wpa-psk "**YOUR_PASSWORD**"

I’m going to install to the 32 GB SD mini card I used for the OS, which means I’m not planning on storing all the blocks. And since flash is less resilient than a HDD, I’m going to disable SWAP.

sudo swapoff --all

Installing the Bitcoin client #

Go to https://github.com/bitcoin/bitcoin/releases and make not of the newest stable release. For me it’s currently 0.19.0.1. So, with that:

cd ~
git clone -b v0.19.0.1 https://github/com/bitcoin/bitcoin.git
cd bitcoin

I’m going to install it without a wallet, since I only want a node.

./autogen.sh
./configure CXXFLAGS="--param ggc-min-expand=1 --param ggc-min-heapsize=32768" --enable-cxx --without-gui --disable-shared --with-pic --disable-tests --disable-bench --enable-upnp-default --disable-wallet
make # This will take a long time, best run in tmux or screen, and grab a beer
sudo make install

Configure #

For this, I want a bitcoin user. sudo adduser bitcoin

Now switch to the new user sudo su - bitcoin

And create the app data directory mkdir ~/.bitcoin

Add the following to ~/.bitcoin/bitcoin.conf

# makes client run in background
daemon=1
# is required by Fail2Ban described below
logips=1
# magic RBP optimisations
maxconnections=40
maxuploadtarget=5000

# Run without SWAP
dbcache=100
maxorphantx=10
maxmempool=50

upnp=1

prune=550 # Only keep the last two days of blocks if like me you are running off a small SD card

Return to the pi user exit

Now create the systemd service to launch the bitcoin client daemon sudo vim /etc/systemd/system/bitcoind.service and give it the following

[Unit]
Description=Bitcoin daemon
After=network.target
[Service]
ExecStart=/usr/local/bin/bitcoind -conf=/home/bitcoin/.bitcoin/bitcoin.conf -pid=/home/bitcoin/.bitcoin/bitcoind.pid
# Creates /run/bitcoind owned by bitcoin
RuntimeDirectory=bitcoind
User=bitcoin
Type=forking
PIDFile=/home/bitcoin/.bitcoin/bitcoind.pid
Restart=on-failure
# Hardening measures
####################
# Provide a private /tmp and /var/tmp.
PrivateTmp=true
# Mount /usr, /boot/ and /etc read-only for the process.
ProtectSystem=full
# Disallow the process and all of its children to gain
# new privileges through execve().
NoNewPrivileges=true
# Use a new /dev namespace only populated with API pseudo devices
# such as /dev/null, /dev/zero and /dev/random.
PrivateDevices=true
# Deny the creation of writable and executable memory mappings.
MemoryDenyWriteExecute=true
[Install]
WantedBy=multi-user.target

Make sure the new service starts on boot sudo systemctl enable bitcoind

Security #

Uncomplicated firewall sudo apt install ufw

Allow limited ssh sudo ufw limit ssh

Allow for main net bitcoin traffic sudo ufw allow 8333 comment "Bitcoin mainnet"

Enable the firewall sudo ufw enable

Preview the enforced rules sudo ufw status verbose

Install Fail2ban sudo apt install fail2ban

See the active jails - for now it will only be sshd sudo fail2ban-client status

Start the bitcoin client sudo systemctl start bitcoind

It will take a few minutes to start, but if you want to monitor its progress switch back to the bitcoin user and enter tail -n 100 -f ~/.bitcoin/debug.log

You will need to figure out how to forward port 8333 to your new btc node depending on your router.

Check it’s accessible from the outside world with curl -sL https://bitnodes.earn.com/api/v1/nodes/me-8333/ | jq
